Focus on LiFePO4 Battery Manufacturing for 17 Years

T Series Plus

TOPBAND batteries are specially designed for golf carts, which can perfectly replace the lead-acid batteries.

Consult Immediately Specifications

RV (4).jpg
Lead acid drop-in T series

Product Design Concept

TOPBAND battery provides advanced Lead acid drop-in battery solution,Widely used in RV, fishing boats, cleaning machines, golf carts, solar energy storage systems and other fields. Battery makes our products available through the best knowledge-based distribution and service organizations for the people and businesses who rely on batteries to work, live, or get away.

Lead Acid Drop-in.jpg

Wide operating temperature range

supports low temperature heating

campatible with various inverters.png
Compatible with various inverters

Equipped with CAN/RS485 interface

Safety and quality guaranteed

/UN38.3/IEC/62619/CE certificated

Bluetooth communication function

support Bluetooth APP upgrade firmware

Long cycle life

6000+Cycles,80% DOD 0.2C/0.2C

parallel connections.png
Support multiple series or parallel connections

Applications

TOPBAND battery provides advanced Lead acid drop-in battery solution,Widely used in RV, fishing boats, cleaning machines, golf carts, solar energy storage systems and other fields.

TECH & SPECS
  • Item/Model
  • R-T12100B
  • R-T12200B
  • R-T12300B
  • Nominal voltage
  • 12.8V
  • 12.8V
  • 12.8V
  • Nominal capacity@0.2C
  • 100Ah
  • 200Ah
  • 300Ah
  • Nominal energy@0.2C
  • 1280Wh
  • 2560Wh
  • 3840Wh
  • Recommend charge current
  • 50A
  • 100A
  • 150A
  • Recommend discharge current
  • 100A
  • 150A
  • 200A
  • Allowed Max.charge current
  • 100A l @25℃
  • 200A l @25℃
  • 300A l @25℃
  • Allowed Max.discharge current
  • 150A l @25℃
  • 200A l @25℃
  • 300A l @25℃
  • Cycle Life
  • ≥6000
  • ≥6000
  • ≥6000
  • Dimension(L*W*H)
  • 308x168x211mm
  • 485x172x225mm
  • 500x235x250mm
  • Weight
  • ≈13.5kg (29.7Lb)
  • ≈25kg (29.4Lb)
  • ≈38kg (90.2Lb)
